High Magnetic Flux Efficiency Toroidal Inductor with Vertical Base and 5 Turns Enameled Wire
  • name
  • name
  • name
  • name

High Magnetic Flux Efficiency Toroidal Inductor with Vertical Base and 5 Turns Enameled Wire

Brand Name: ZXY
MOQ: Negotiable
Price: Negotiable
Packaging Details: Carton
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen Guangdong
Certification:
RoHS、ISO9001、CE
Highlight:

High Magnetic Flux Efficiency Toroidal Inductor

,

Vertical With Base Toroidal Inductor

,

5 Turns Enameled Wire Ring Core Inductor

Product Description
High Magnetic Flux Efficiency Magnetic Ring Inductor
This vertical mount inductor features a high magnetic flux efficiency ring core with 5 turns of 0.6mm diameter enameled wire (1mm OD), approximately 20cm in length, delivering 10µH inductance. The innovative vertical base design provides closed magnetic circuit performance while saving valuable PCB space.
Core Design Advantages
  • Closed Magnetic Circuit: Minimizes magnetic leakage and electromagnetic interference with superior anti-interference capability
  • High Inductance/Volume Ratio: Delivers substantial inductance in compact dimensions
  • Low EMI Radiation: Ideal for applications with stringent electromagnetic compatibility requirements
Vertical Mount Benefits
  • Space Optimization: Vertical installation utilizes 3D space rather than consuming valuable PCB surface area
  • Secure Mounting: Stable base provides mechanical robustness against vibration and stress
  • Manufacturing Friendly: Standard through-hole pins compatible with automated insertion and wave soldering processes
  • Standard Pitch: Typical 2.54mm (0.1 inch) pin spacing for easy integration
Electrical Performance
Precise specifications for magnetic core, wire gauge, and winding turns ensure consistent electrical parameters including inductance value (10µH), saturation current, and DC resistance with excellent batch-to-batch repeatability.
Technical Specifications
Feature Category Specification / Description
Core Type & Shape High Magnetic Flux Efficiency Toroidal (Ring) Core
Inductance Value 10 µH (Nominal, at specified test frequency)
Winding Specification 5 Turns (5TS) using Enameled Copper Wire
Wire Gauge Conductor Diameter: 0.6mm; Overall Diameter (with insulation): ~1.0mm
Approx. Wire Length 20 cm
Mechanical Form Vertical Mounting (Axial) with Insulating Base
Termination Through-Hole (PTH) Pins, typically on standard pitch (e.g., 2.54mm)
Key Electrical Performance Low Magnetic Leakage, High Current Handling, Stable Parameters
Key Mechanical Advantages Space-Efficient, Secure & Robust, Automation-Friendly
Primary Function Energy storage & filtering in power conversion circuits
Typical Applications Switching Power Supplies, DC-DC Converters, Power Filtering Networks, EMI Suppression
