✅ Accurate parameters: rated voltage 690V, inductance 140 μ H, high-performance silicon steel core, low loss design, ensuring stable system operation. ✅ Industrial grade protection: Thick wooden box packaging, moisture-proof and shockproof, suitable for long-distance transportation and harsh environments, zero damage upon arrival. ✅ Full inspection commitment: undergo a 72 hour aging test and withstand voltage test before leaving the factory, with a 100% pass rate, accompanied by authoritative testing reports. ✅ Service guarantee: Support technical consultation and rapid after-sales response, providing full support for your project. Application areas: Photovoltaic inverter system | Industrial frequency converter | Energy storage equipment | New energy generation Cooperation Hotline: 13554723725 (Welcome to bulk order, support customized solutions!)

1. Enhanced Efficiency & Reduced Losses Lower Core Losses: Dual magnetic rings (typically using two toroidal cores) distribute magnetic flux more evenly, reducing eddy current and hysteresis losses compared to single-core designs. This improves overall inverter efficiency (e.g., from 97% to 98.5%+). Reduced Skin Effect: Flat copper wire windings on dual rings minimize AC resistance at high frequencies, further cutting energy losses. 2. Improved Thermal Management Heat Dissipation: Dual rings spread heat generation across two cores, preventing localized overheating. This is critical for PV inverters operating under continuous high-current conditions. Longer Lifespan: Lower operating temperatures extend the lifespan of magnetic components and nearby electronics (e.g., IGBTs, capacitors). 3. Higher Power Density & Compact Design Space Optimization: Dual-ring designs allow for more compact layouts while handling the same power as bulkier single-core solutions. This is vital for modern inverters where size and weight matter (e.g., rooftop solar systems). Scalability: Easier to scale power output by adjusting the number of turns or core materials without redesigning the entire magnetic assembly. 4. Better Electromagnetic Interference (EMI) Suppression Balanced Flux Cancellation: Dual rings can be configured to cancel out stray magnetic fields, reducing EMI that could disrupt sensitive PV system electronics (e.g., MPPT controllers, communication circuits). Compliance with Standards: Helps meet stringent EMI/EMC regulations (e.g., CISPR, IEEE 1547) for grid-tied inverters. 5. Increased Reliability & Fault Tolerance Redundancy: If one magnetic ring fails (e.g., due to saturation or thermal stress), the second ring can temporarily sustain operation, improving system robustness. Lower Saturation Risk: Splitting the magnetic load between two cores reduces the chance of core saturation during power surges (e.g., cloud transients in solar arrays). 6. Optimized for High-Frequency Switching Support for SiC/GaBT Devices: Dual-ring inductors are better suited for high-frequency switching (20–100 kHz) in advanced inverters using silicon carbide (SiC) or gallium nitride (GaN) transistors, minimizing switching losses. Reduced Ripple Current: Dual cores can filter high-frequency current ripple more effectively, ensuring cleaner DC-AC conversion. 7. Material & Cost Advantages   Flexible Core Materials: Allows combinations of different materials (e.g., ferrite for high frequency + powdered iron for DC bias) to optimize cost and performance. Lower Total Cost of Ownership (TCO): Despite higher initial cost, dual rings improve efficiency and reliability, reducing long-term maintenance and energy losses.

Launches high-efficiency intelligent inverter transformer to empower green energy and intelligent manufacturing   Shenzhen 2025.7.10-- With the acceleration of the global energy transition and the upgrading of industrial intelligence, inverter technology has become the key to improving energy efficiency. Recently, Zhixiangyuan Electronics Co., Ltd (hereinafter referred to as “Zhixiangyuan”) formally announced the expansion of new business, the launch of self-developed inverter transformer series products, targeting industrial energy-saving transformation, new energy power generation, rail transportation and other high-growth markets, to provide customers with more efficient and more reliable power solutions.   Driven by market demand, inverter transformer becomes a new blue ocean Under the background of “double carbon” target, the demand for power quality, energy efficiency management and equipment intelligence in various industries continues to rise. Traditional transformers are difficult to meet the demand for efficient and stable operation under the scenarios of frequency conversion drive, new energy grid connection, etc. Inverter transformers are becoming the new favorites in the market due to their advantages of wide voltage adaptability, low loss and high reliability.   Zhixiangyuan general manager Hu Zhiqiang said:   "Inverter transformer is one of the core components of the future power system. Relying on years of experience in transformer research and development, combined with advanced power electronics technology, we have launched a new generation of frequency converter transformers to help customers reduce energy consumption, improve production efficiency, and contribute to green and low-carbon development."   Leading technology to create differentiated competitiveness The inverter transformer series launched by Zhixiangyuan this time has the following core advantages:   High efficiency and energy saving: adopting high-frequency core materials and optimized design, the efficiency is up to 98% or more, reducing energy consumption by 15%-30% compared with traditional products;   Intelligent regulation: built-in IoT monitoring module, real-time monitoring of temperature, load and other data, support for remote operation and maintenance and fault warning;   High compatibility: adapted to mainstream inverter brands, widely used in wind power, photovoltaic, metallurgy, mining, water and other fields.   At present, the product has passed the national energy efficiency certification and ISO 60076-31 international standard test, and has obtained a number of patents.

What a Power Transformer is and What it Does A power transformer is an electrical device that transfers electrical energy between two or more circuits through electromagnetic induction. It is a key component in power distribution systems, enabling efficient transmission of electricity over long distances with minimal energy loss. What a Power Transformer Does: Changes Voltage Levels Steps up voltage (increases) for efficient long-distance transmission (e.g., from 11 kV to 220 kV). Steps down voltage (decreases) for safe distribution to homes and industries (e.g., from 33 kV to 415 V). Reduces Energy Loss Higher voltage = lower current = less resistive (I²R) loss in transmission lines. Provides Electrical Isolation Separates two circuits while allowing power transfer, improving safety. Impedance Matching Ensures maximum power transfer between different parts of an electrical system. Types of Power Transformers: Step-Up Transformer (Increases voltage at power plants) Step-Down Transformer (Decreases voltage for end-users) Distribution Transformer (Used in local power grids) Power Transformer (Handles high voltages in transmission networks) Key Components: Core (Laminated steel to reduce eddy currents) Windings (Primary & secondary coils) Cooling System (Oil or air-cooled) Bushings (Insulated terminals for connections) Applications: Electricity grids (Transmission & distribution) Industrial plants (Machinery power supply) Renewable energy systems (Solar/wind farms) Power transformers ensure electricity is delivered efficiently and safely from generation plants to consumers. ⚡

Introduction​ In the intricate world of electronics, passive components play a pivotal role in ensuring the seamless operation of various devices. Among these, the power inductor stands out as a fundamental yet crucial element. A power inductor is an electronic component that stores energy in the form of a magnetic field when an electric current passes through it. It resists changes in current, making it an essential part of power supply circuits, filtering out high - frequency noise, and maintaining a stable current flow. This case study delves into the realm of plug - in power inductors, with a specific focus on how Zhixiangyuan, a leading manufacturer in the industry, has mastered their production and application.​ What is a Plug - in Power Inductor?​ A plug - in power inductor, as the name implies, is a type of power inductor designed to be plugged into a circuit board. It typically consists of a coil of wire wound around a magnetic core. The core material can vary, with ferrite, iron, or powdered iron being common choices, each offering different magnetic properties suitable for various applications.​ When current flows through the coil, a magnetic field is generated around it. According to Faraday's law of electromagnetic induction, this magnetic field induces an electromotive force (EMF) that opposes the change in current. In a direct - current (DC) circuit, the power inductor allows a steady - state current to flow with minimal resistance. However, in an alternating - current (AC) or a circuit with fluctuating DC, the inductor's ability to resist changes in current becomes prominent.​ Key Functions of Plug - in Power Inductors​ 1.Energy Storage and Release​ One of the primary functions of a power inductor is energy storage. In a DC - DC converter, for example, during the "on" phase of the switching cycle, the inductor stores energy in its magnetic field as current builds up through the coil. When the switch is turned "off," the inductor releases this stored energy, maintaining a continuous flow of current to the load. This energy - storage and - release mechanism helps in smoothing out the output current and voltage, reducing ripple and ensuring a more stable power supply.​ 2.Noise Suppression​ High - frequency noise is a common issue in electronic circuits, which can interfere with the proper functioning of sensitive components. Plug - in power inductors act as low - pass filters, blocking high - frequency signals while allowing low - frequency signals to pass through. They do this by presenting a high impedance to high - frequency currents, effectively diverting the noise away from the main circuit path. This property is particularly crucial in applications such as power supplies for microprocessors, where a clean power signal is essential for the reliable operation of the device.​ 3.Current Smoothing​ In power supply circuits, especially those with rectifiers, the output current often contains significant ripple due to the nature of the rectification process. Power inductors are used in conjunction with capacitors to form filter circuits that smooth out this ripple. By resisting changes in current, the inductor helps to make the current flow more steadily, reducing the fluctuations and providing a more consistent power source for the load.​ Zhixiangyuan's Plug - in Power Inductors: A Closer Look​ Company Background​ Zhixiangyuan, founded in 2004, has emerged as a prominent player in the field of electronic component manufacturing. With a management team hailing from the technical ranks of Taiyo Yuden's foundry, the company brings with it nearly 20 years of accumulated experience in the production of inductors and transformers. This wealth of experience has been instrumental in enabling Zhixiangyuan to develop high - quality, reliable plug - in power inductors.​ Product Range and Features​ Zhixiangyuan offers a diverse range of plug - in power inductors, catering to various applications across multiple industries. Their inductors are known for several key features:​ High Inductance Values: Zhixiangyuan's power inductors are designed to provide a wide range of inductance values, allowing for precise tuning in different circuit designs. Whether it's a low - inductance requirement for high - frequency applications or a high - inductance need for power - hungry devices, Zhixiangyuan has the product to meet the demand.​ Low DC Resistance: The company utilizes advanced manufacturing techniques and high - quality materials to minimize the DC resistance of their inductors. This results in lower power losses in the form of heat, improving the overall efficiency of the circuit. A lower DC resistance also means that more of the input power can be delivered to the load, rather than being dissipated as heat in the inductor.​ High Current - Carrying Capacity: Many of Zhixiangyuan's plug - in power inductors are engineered to handle high currents. This makes them suitable for applications such as power supplies for industrial equipment, automotive electronics, and high - performance computing devices, where large amounts of current are required to drive the load.​ Excellent Magnetic Core Materials: Zhixiangyuan carefully selects magnetic core materials based on the specific requirements of each product. For applications requiring high saturation currents and low losses at low frequencies, they may use iron - based cores. In contrast, for high - frequency applications where minimizing core losses is crucial, ferrite cores are preferred. This attention to detail in material selection ensures that their inductors perform optimally in different operating conditions.​ Application in the Power Supply of a Smart Home Device​ To illustrate the practical application of Zhixiangyuan's plug - in power inductors, let's consider a case in the smart home industry. Suppose a smart home device manufacturer is developing a new generation of smart hubs that need to handle multiple wireless communication protocols simultaneously while also powering various sensors and actuators.​ The power supply for this smart hub requires a stable and clean power source to prevent interference with the sensitive wireless communication modules. Zhixiangyuan's plug - in power inductor is integrated into the power supply circuit. It first stores energy during the charging phase of the power supply's switching cycle. When the power source transitions to the discharging phase, the inductor releases this stored energy, ensuring a continuous and stable current flow to the smart hub's components.​ The inductor also plays a vital role in suppressing high - frequency noise generated by the switching power supply. This noise, if left unchecked, could interfere with the wireless signals of the smart hub, leading to communication errors or dropped connections. By acting as a low - pass filter, the Zhixiangyuan power inductor blocks the high - frequency noise, allowing only the clean, low - frequency power signal to reach the smart hub's circuitry. As a result, the smart hub operates smoothly, providing reliable communication and control for all the connected smart home devices.​ Application in the Audio Amplifier of a High - End Speaker System​ In another example, in the audio industry, a high - end speaker system manufacturer is aiming to enhance the sound quality of their new product line. The audio amplifier in these speakers requires a power supply that can deliver a clean and stable current to the amplifier circuits to reproduce accurate and distortion - free sound.​ Zhixiangyuan's high - current - carrying plug - in power inductor is incorporated into the power supply of the audio amplifier. The inductor helps in smoothing out the current fluctuations in the power supply, which are common in audio amplifier circuits due to the dynamic nature of the audio signals. By providing a steady current, the inductor enables the audio amplifier to amplify the audio signals more accurately, resulting in a more detailed and immersive sound experience for the listener.​ Moreover, the low DC resistance of Zhixiangyuan's inductor ensures that there is minimal power loss in the power supply circuit. This is crucial in high - end audio systems, where every bit of power efficiency matters to achieve the best possible sound quality. The use of high - quality magnetic core materials in the inductor also helps in reducing magnetic interference, which could otherwise introduce unwanted noise into the audio signal.​ Conclusion​ In conclusion, plug - in power inductors are essential components in modern electronics, performing critical functions such as energy storage, noise suppression, and current smoothing. Zhixiangyuan, with its rich experience and commitment to quality, has been successful in manufacturing high - performance plug - in power inductors that meet the diverse needs of various industries. Their products, with features like high inductance values, low DC resistance, and high current - carrying capacity, have found applications in a wide range of devices, from smart home electronics to high - end audio systems. As the demand for more efficient and reliable electronic devices continues to grow, Zhixiangyuan's plug - in power inductors are well - positioned to play a significant role in enabling the next generation of technological advancements.

With the increasing popularity of modern electronic devices, the problem of noise interference in audio systems has become increasingly prominent. As a professional audio equipment supplier directly manufactured by Zhixiangyuan factory, we strongly recommend using Ground Loop Noise Isolator to solve these common problems. This article will provide a detailed explanation of the reasons for choosing to use this device and its significant advantages. What is ground loop noise? Grounding loop noise refers to the current circulation caused by different grounding potentials between electronic devices when there are multiple grounding paths between them. This current can introduce unpleasant buzzing or humming sounds in the audio signal. This type of noise is particularly common in professional audio systems, home theaters, recording studios, and car audio systems.     Five reasons to choose Ground Loop Noise Isolator 1. Thoroughly eliminate ground loop noise The Ground Loop Noise Isolator effectively blocks the ground loop current through transformer isolation or optoelectronic isolation technology, fundamentally eliminating noise interference caused by ground potential differences. Compared to other temporary solutions, it can provide a more thorough and long-lasting noise cancellation effect. 2. Maintain high fidelity of audio signals High quality noise isolators use high-performance transformers and precision circuit designs, which can eliminate noise while maximizing the integrity and clarity of the original audio signal. The isolators produced by Zhixiangyuan pay special attention to high-frequency response and low-frequency extension to ensure that sound quality is not affected. 3. Easy to install, plug and play Ground Loop Noise Isolators typically use standard RCA, XLR, or TRS interfaces and require no complex setup or professional technical support. Simply connect them in series between the signal source and amplifier to achieve immediate results. This convenience makes it an ideal choice for system integrators and end-users. 4. Wide compatibility and application scenarios Whether it's professional recording equipment, DJ equipment, home theater systems, car speakers, or computer audio interfaces, Ground Loop Noise Isolator can work effectively. Zhixiangyuan offers multiple models to meet different impedance matching and signal level requirements. 5. Economically efficient long-term solutions Compared to rewiring or purchasing more expensive balancing equipment, using noise isolators is a highly cost-effective solution. It can solve over 90% of grounding noise problems, extend equipment lifespan, and reduce equipment replacement costs caused by noise issues.   Additional advantages of Zhixiangyuan Ground Loop Noise Isolator As a factory direct sales manufacturer, Zhixiangyuan provides noise isolators with the following unique advantages: Strict quality control: every link from raw materials to finished products undergoes rigorous testing Optimized circuit design: specifically designed for high fidelity audio applications, with better noise cancellation effects Durable structure: using high-quality components and sturdy casing to ensure long-term reliable performance Price advantage: The factory direct sales model eliminates intermediate links and provides customers with more competitive prices Professional technical support: providing comprehensive pre-sales consultation and after-sales service   Conclusion In complex electronic environments, Ground Loop Noise Isolator is one of the most effective tools for addressing ground noise issues in audio systems. Choosing high-quality noise isolators produced by Zhixiangyuan can not only immediately improve the signal-to-noise ratio of the audio system, but also provide long-term protection for your equipment, ensuring a pure and interference free sound experience. Whether you are a professional audio engineer or an ordinary audio enthusiast, this is a solution worth investing in. If you need more detailed information about our Ground Loop Noise Isolator product or professional advice for your specific application scenario, please feel free to contact the technical support team of Zhixiangyuan manufacturer at any time.
