EE10 SMPS Flyback Transformer High Frequency Transformer Nickel Steel Sheet T1B

1.Product Description

EE10 SMPS flyback high-frequency transformer, made of nickel steel sheet core (T1B material), designed for switching power supply (SMPS), by virtue of the high permeability of nickel steel sheet, low-loss characteristics, to achieve high efficiency energy conversion and stable signal transmission, high operating frequency, which can effectively reduce the electromagnetic interference, with excellent saturation characteristics and temperature stability to meet the needs of consumer electronics, industrial control and other fields on the miniaturization of power supplies, high reliability, is the ideal choice to optimize the performance of power supplies. It can meet the needs of consumer electronics, industrial control and other fields for miniaturization of power supplies, high reliability, and is the ideal choice for optimizing the performance of power supplies.

1, Efficient energy conversion and low loss
Nickel steel sheet (T1B) has high magnetic permeability characteristics (up to tens of thousands of μ values), reducing hysteresis losses. With a flyback topology structure, the power conversion efficiency exceeds 90%, making it suitable for low-power SMPS (such as adapters below 50W).

2, High frequency stable working ability
Supports high-frequency operation above 100kHz, with high magnetic core saturation flux density (Bs), suppressing magnetic saturation phenomena at high frequencies, ensuring dynamic response speed of switching power supplies, and reducing transformer volume (reduced by 30% compared to silicon steel sheets).

3, Anti interference and temperature stability
Low magnetic core loss (loss<1W/kg at 100kHz/0.3T) reduces heat generation, operating temperature range -40 ℃~125 ℃; Nickel steel sheets have strong magnetic shielding properties, reduce EMI interference, and comply with electromagnetic compatibility standards such as FCC and CE.

4, Compact structure and high reliability
EE10 skeleton is designed for miniaturization, suitable for scenarios such as consumer electronics (such as mobile phone chargers), industrial control modules, etc; T1B material is resistant to mechanical vibration and impact, with a long-term magnetic performance attenuation of less than 5%, ensuring the reliability of the power system.
