Magnetic Bar Inductor Pin 2R2 3R3 5R6 6R8 5x20 DC Line Filter Hollow Air Coil

Brand Name:	ZXY
Model Number:	ZXY
MOQ:	Negotiable
Price:	Negotiable
Packaging Details:	1000pieces / Carton
Payment Terms:	T/T paypal xtransfer

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong,shenzhen

Certification:

RoHS,ISO9001-2001

Number Of Turns:

Customized

Inductor Name:

Magnetic Bar Inductor

Color Of Bobbin:

Customized

Inductor Material:

Copper Wire

Place Of Origin:

Huizhou.China

Inductor Shape:

Hollow

Supply Ability:

1000K-pcs/month

Highlight:

Magnetic Bar Pin Inductor

5x20 Filter Coil Inductor

DC Filter Coil Inductor

Product Description

Magnetic Bar Inductor Pin 2R2 3R3 5R6 6R8 5x20 DC Line Filter Hollow Air Coil

1.Product Description

A magnetic bar inductor is an inductor whose structure is a coil that wraps a wire or a coil around a soft iron bar so that magnetic flux can enter from one port of the core and escape at the other end.

The main function of magnetic bar inductance is used in frequency selection circuit, filter circuit, audio amplifier circuit, radio transceiver circuit and power filter circuit.

2. Features:

Feature	Explanation in Application
High Magnetic Permeability	- Enables efficient magnetic field concentration. In radio - frequency (RF) circuits, it helps in achieving high inductance values with relatively fewer turns of wire. This is crucial for applications like tuning circuits in radios or wireless communication devices, where precise inductance is required to resonate at specific frequencies, ensuring accurate signal reception and transmission.
Open - circuit Magnetic Structure	- Allows for better interaction with external magnetic fields. In wireless charging systems, this open structure facilitates the coupling of magnetic fields between the transmitter and receiver coils. Although it may cause some electromagnetic interference (EMI), in such applications, the ability to transfer energy across open space is more important. Additionally, it offers flexibility in circuit layout as components can be placed around the inductor more easily.
Design Flexibility and Adjustability	- Permits easy modification of inductance and other parameters. In experimental circuits or custom - designed electronics, engineers can quickly adjust the inductance by changing the number of turns, wire gauge, or the type of magnetic bar. This adaptability is valuable when fine - tuning the performance of a circuit to meet specific requirements, such as optimizing the filtering characteristics in a power supply circuit.
Power - handling Capability	- Can handle different power levels depending on design. In low - power audio circuits, it can be used for audio signal processing and filtering, ensuring clear sound output. In small - scale power conversion circuits, appropriately designed magnetic bar inductors can efficiently transfer and convert electrical energy, making them suitable for applications like DC - DC converters in portable devices.
Frequency - dependent Performance	- Displays distinct characteristics across different frequencies. At low frequencies, it maintains a relatively stable inductance, effectively suppressing low - frequency noise and interference. In high - frequency applications, while factors like skin effect and magnetic hysteresis may cause a decrease in inductance and Q - factor, optimized designs can extend its useful frequency range. This makes it suitable for a wide range of applications, from low - frequency power supply filtering to high - frequency communication signal processing.
Cost - effectiveness	- Offers a cost - efficient solution. With a relatively simple structure and easy - to - implement manufacturing process, magnetic bar inductors are an attractive option for cost - sensitive applications. In consumer electronics, where large - scale production is common, using magnetic bar inductors can help keep the production cost down without sacrificing significant performance, thus enhancing the product's market competitiveness.

Magnetic Bar Inductor Pin 2R2 3R3 5R6 6R8 5x20 DC Line Filter Hollow Air Coil 0
