Flat Copper Wire Air Core Winding Coil Hollow High Power High Current Inductor

Brand Name:	ZXY
Model Number:	Customized
MOQ:	Negotiable
Price:	Negotiable
Packaging Details:	100pieces / Carton size:380mm325mm345mm
Payment Terms:	T/T paypal xtransfer

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen,China

Certification:

RoHS,ISO9001,CE

Product Name:

Flat Copper Wire Air Coil

Supplier Type:

Original Manufacturer

Parameters:

Customized

Application:

For Board And Suppression Components

Inductance:

Customized

Number Of Coils:

Customized

Supply Ability:

2000K-pcs/month

Highlight:

2R2 4R7 SMD Inductor 101uH 100uH

2R2 smd inductor 15uH

4Shielded R7 SMD Inductor

Product Description

Air Core Winding Coil Hollow High Power High Current Inductor Flat Copper Wire

1.Product Description

Flat Copper Wire Air Core is a flat copper wire wound inductor with no magnetic core. Its unique design combines the features of flat copper wire and air core structure, which is widely used in high frequency circuits, RF communication and power management.

Priduct name	Flat copper wire air coil
Place of Origin	Guangdong, China
Brand Name	ZXY
Dimensions	Customized
Usage	Power electronics,daily living equipment
DC Resistance (mΩ)	Customized
Parameters	Customized
Exports	Worldwide
OEM/ODM	Acceptable

2.Functionality

1.Signal Filtering
Used to filter out high-frequency noise in circuits to improve signal quality.

2.Energy Storage
Used as an energy storage element for power management circuits (e.g. DC-DC converters).

3.Resonant Circuit
Used in RF circuits as resonators and tuning circuits.

4.Impedance Matching
Used to match circuit impedance to optimize signal transmission efficiency.

5.Anti-Electromagnetic Interference (EMI)
Suppresses electromagnetic interference in circuits and improves the electromagnetic compatibility (EMC) of the system.

Characteristic	Description
High-Frequency Performance	Excellent performance in high-frequency and RF applications due to air core design.
Low Loss	Flat copper wire reduces skin effect, minimizing resistance losses at high frequencies.
High Current Capacity	Larger cross-sectional area of flat wire allows for higher current handling.
Low DC Resistance (DCR)	Low resistance of flat copper wire reduces energy loss and improves efficiency.
No Magnetic Saturation	Air core design eliminates magnetic saturation issues, suitable for high-current applications.
Temperature Stability	Stable performance across a wide temperature range due to absence of magnetic core.

3.Applications

Flat copper wire air coil is mainly used in the fields of induction acceptance, prefocus, magnetic card, magnetic head, high current line separation, low voltage electrical appliances, industrial control, household appliances, car electronics, SMT mounting, mobile phones, wireless transceiver, electronic navigation device, power regulator, amplifier, supplier and filter.
